Winkhaus primePort SK (the slide-tilt fitting)

Modern architecture focuses on large-format window elements that meet high requirements in terms of design, security, comfort and energy efficiency. Winkhaus pimePort SK is a comfortable fitting system for modern windows and balcony doors with slide and tilt function.

Functionality, design and safety

The three versions of our primePort SK slide-tilt fitting system offer a simple solution for individual living comfort. primePort SK 100 S and SK 160 S allow easy opening by sliding or tilting, whereas primePort SK 160 Z and SK 220 Z enable safe operation of large window sashes. primePort PAS ensures a healthy indoor climate through optimal ventilation. All fittings combine intuitive handling, security and convenience for pleasant use.

primePort SK variants

primePort SK-S

The primePort SK S slide-tilt fitting system opens effortlessly: Slide or tilt as desired. A gentle 90-degree turn, the sash can be easily brought into the sliding position, while a 180-degree handle rotation enables the tilt position to be accessed. A convenient and intuitive way of opening the door, similar to operating a turn-tilt window.

primePort SK-Z

The intelligent primePort SK-Z fitting technology enables large window sashes weighing up to 220 kg to be tilted safely and effortlessly. By turning the handle 180 degrees, the sash is automatically positioned correctly in the tilt position. This virtually eliminates faulty operation, which increases safety and convenience. primePort SK-Z is particularly suitable for large window sashes and offers a reliable solution for demanding users.

primePort PAS

The primePort PAS parallel action slide fitting system enables healthy room air circulation
and at the same time offers additional security protection for animal residents. Sash weights of up to 160 kg are possible. Thanks to the parallel opening position of about 6 mm, fresh air can gently enter the room without it cooling down too much or allowing animals to escape. This circumferential parallel action function ensures optimum ventilation convenience creating a cosy and safe atmosphere. Of course, the sashes can also be opened completely to take full advantage of the sliding window door. This ensures an ideal combination of modern design and practical functionality.

Advantages of primePort SK/PAS technology:

Intuitive operation.
Smooth mechanics.
Burglar resistance up to resistance class RC2 possible for all opening scheme A variants.
Parallel action for particularly efficient and safe ventilation available.
Large opening width of 135 mm for deep profiles.
Durable, certified activPilot central locking system.
Modern design of the cap and covering profiles, available in seven colours.
